T Section Steel Weight Chart

	Model	Section size （mm）					Section size	Weight	Section parameter							CORR H Beam
	H*W	h	B	t1	t2	r	Cm²	kg/m	Moment of inertia		Radius of inertia		Section modulus		Center of gravity	Series
									Cm⁴		cm		Cm³		cm
									Ix	IY	ix	iY	Wx	WY	Cx	Model
TW	50×100	50	100	6	8	10	10.95	8.56	16.1	66.9	1.21	2.47	4.03	13.4	1	100×100
	62.5×125	62.5	125	6.5	9	10	15.16	11.9	35	147	1.52	3.11	6.91	23.5	1.19	125×125
	75×150	75	150	7	10	13	20.28	15.9	66.4	282	1.81	3.73	10.8	37.6	1.37	150×150
	87.5×175	87.5	175	7.5	11	13	25.71	20.2	115	492	2.11	4.37	15.9	56.2	1.55	175×175
	100×200	100	200	8	12	16	32.14	25.2	185	801	2.4	4.99	22.3	80.1	1.73	200×200
	100×200	#100	204	12	12	16	36.14	28.3	256	851	2.66	4.85	32.4	83.5	2.09	200×200
	125×250	125	250	9	14	16	46.09	36.2	412	1820	2.99	6.29	39.5	146	2.08	250×250
	125×250	#125	255	14	14	16	52.34	41.1	589	1940	3.36	6.09	59.4	152	2.58	250×250
	150×300	#147	302	12	12	20	54.16	42.5	858	2760	3.98	7.14	72.3	183	2.83	300×300
		150	300	10	15	20	60.22	47.3	798	3380	3.64	7.49	63.7	225	2.47
		150	305	15	15	20	67.72	53.1	1110	3550	4.05	7.24	92.5	233	3.02
	175×350	#172	348	10	16	20	73	57.3	1230	5620	4.11	8.78	84.7	323	2.67	350×350
	175×350	175	350	12	19	20	86.94	68.2	1520	6790	4.18	8.84	104	388	2.86	350×350
	200×400	#194	402	15	15	24	89.62	70.3	2480	8130	5.26	9.52	158	405	3.69	400×400
		#197	398	11	18	24	93.8	73.6	2050	9460	4.67	10	123	476	3.01
		200	400	13	21	24	109.7	86.1	2480	11200	4.75	10.1	147	560	3.21
		#200	408	21	21	24	125.7	98.7	3650	11900	5.39	9.73	229	584	4.07
		#207	405	18	28	24	148.1	116	3620	15500	4.95	10.2	213	766	3.68
		#214	407	20	35	24	180.7	142	4380	19700	4.92	10.4	250	967	3.9
TM	74×100	74	100	6	9	13	13.63	10.7	51.7	75.4	1.95	2.35	8.8	15.1	1.55	150×100
	97×150	97	150	6	9	16	19.88	15.6	125	254	2.5	3.57	15.8	33.9	1.78	200×150
	122×175	122	175	7	11	16	28.12	22.1	289	492	3.2	4.18	29.1	56.3	2.27	250×175
	147×200	147	200	8	12	20	36.52	28.7	572	802	3.96	4.69	48.2	80.2	2.82	300×200
	170×250	170	250	9	14	20	50.76	39.9	1020	1830	4.48	6	73.1	146	3.09	350×250
	200×300	195	300	10	16	24	68.37	53.7	1730	3600	5.03	7.26	108	240	3.4	400×300
	220×300	220	300	11	18	24	78.69	61.8	2680	4060	5.84	7.18	150	270	4.05	450×300
	250×300	241	300	11	15	28	73.23	57.5	3420	3380	6.83	6.8	178	226	4.9	500×300
	250×300	244	300	11	18	28	82.23	64.5	3620	4060	6.64	7.03	184	271	4.65	500×300
	300×300	291	300	12	17	28	87.25	68.5	6360	3830	8.54	6.63	280	256	6.39	600×300
		294	300	12	20	28	96.25	75.5	6710	4510	8.35	6.85	288	301	6.08
		#297	302	14	23	28	111.2	87.3	7920	5290	8.44	6.9	339	351	6.33

Model		Section size (mm)					Section size	Weight	Section parameter							CORR H Beam
	H*W	h	B	t1	t2	r	Cm²	kg/m	Moment of inertia		Radius of inertia		Section modulus		Center of gravity	Series
									Cm⁴		cm		Cm³		cm
									Ix	IY	ix	iY	Wx	WY	Cx	Model
TW	50×50	50	50	5	7	10	6.079	4.79	11.9	7.45	1.4	1.11	3.18	2.98	1.27	100×50
	62.5×60	62.5	60	6	8	10	8.499	6.67	27.5	14.6	1.8	1.31	4.96	4.88	1.63	125×60
	75×75	75	75	5	7	10	9.079	7.11	42.7	24.8	2.17	1.65	7.46	6.61	1.78	150×75
	87.5×90	87.5	90	5	8	10	11.6	9.11	70.7	48.8	2.47	2.05	10.4	10.8	1.92	175×90
	100×100	99	99	4.5	7	13	11.8	9.26	94	56.9	2.82	2.2	12.1	11.5	2.13	200×100
	100×100	100	100	5.5	8	13	13.79	10.8	115	67.1	2.88	2.21	14.8	13.4	2.27	200×100
	125×125	124	124	5	8	13	16.45	12.9	208	128	3.56	2.78	21.3	20.6	2.62	250×125
	125×125	125	125	6	9	13	18.94	14.8	249	147	3.62	2.79	25.6	23.5	2.78	250×125
	150×150	149	149	5.5	8	16	20.77	16.3	395	221	4.36	3.23	33.8	29.7	3.22	300×150
	150×150	150	150	6.5	9	16	23.76	18.7	465	254	4.42	3.27	40	33.9	3.38	300×150
	175×175	173	174	6	9	16	26.6	20.9	681	396	5.06	3.86	50	45.5	3.68	350×175
	175×175	175	175	7	11	16	31.83	25	816	492	5.06	3.93	59.3	56.3	3.74	350×175
	200×200	198	199	7	11	16	36.08	28.3	1190	724	5.76	4.48	76.4	72.7	4.17	400×200
	200×200	200	200	8	13	16	42.06	33	1400	868	5.76	4.54	88.6	86.8	4.23	400×200
	225×200	223	199	8	12	20	42.54	33.4	1880	790	6.65	4.31	109	79..4	5.07	450×200
	225×200	225	200	9	14	20	48.71	38.2	2160	936	6.66	4.38	124	93.6	5.13	450×200
	250×200	248	199	9	14	20	50.64	39.7	2840	922	7.49	4.27	150	92.7	5.9	500×200
		250	200	10	16	20	57.12	44.8	3210	1070	7.5	4.33	169	107	5.96
		#253	201	11	19	20	65.65	51.5	3 670	1290	7.48	4.43	190	128	5.95
TM	300×200	298	199	10	15	24	60.62	47.6	5 200	991	9.27	4.04	236	100	7.76	600×200
		300	200	11	17	24	67.6	53.1	5820	1140	9.28	4.11	262	114	7.81
		#303	201	12	20	24	76.63	60.1	6580	1360	9.26	4.21	292	135	7.76
