11 Material Properties You Need to Know for Optimal Performance

1. Mechanical properties of materials under uniaxial static tension

1. Definition:

Craze: Craze is a type of defect that occurs in the deformation process of polymer materials. It appears as a silver color due to its low density and high reflectiveness to light. Craze occurs in the weak or defective parts of polymer materials.

Superplasticity: Under certain conditions, the material exhibits a very large elongation (around 1000%) without necking or breaking, which is called superplasticity. The proportion of strain generated by grain boundary sliding, εg, in total strain, εt, is typically between 50% and 70%, indicating that grain boundary sliding plays a major role in superplastic deformation.

Brittle Fracture: Before the material fractures, there is no obvious macroscopic plastic deformation, and no warning signs. This process is often sudden and rapid, making it very dangerous.

Ductile Fracture: The fracture process that shows obvious macroscopic plastic deformation before and during the fracture. In ductile fracture, the crack propagation process is generally slow and consumes a large amount of plastic deformation energy.

Cleavage Fracture: The brittle fracture along a specific crystal plane caused by the destruction of bonding bonds between atoms under normal stress is called cleavage fracture. The cleavage step, river pattern, and tongue pattern are the basic microscopic characteristics of cleavage fracture.

Shear Fracture: Shear fracture is the fracture caused by material sliding and separation along the slip plane under shear stress. Micropore aggregation fracture is a common mode of ductile fracture in materials. The fracture surface is usually dark gray and fibrous in macro, while the micro fracture surface has a characteristic pattern of many “dimples” distributed on the surface.

2. Try to describe the difference between ductile fracture and brittle fracture. Why is brittle fracture the most dangerous?

Type of stress, degree of plastic deformation, presence or absence of omen, and speed of crack propagation.

3. What is the difference between breaking strength σc and tensile strength σb?

If the material experiences no plastic deformation or very little plastic deformation before fracture, and brittle fracture occurs without necking, then the critical stress, σc, is equal to the breaking stress, σb.

However, if necking occurs before fracture, σc and σb are not equal.

4. What scope does Griffith formula apply to and under what circumstances should it be revised?

The Griffith formula is only appropriate for brittle solids containing microcracks, such as glass, inorganic crystal materials, and ultra-high strength steel.

For many engineering structural materials, such as structural steel and polymer materials, the crack tip undergoes significant plastic deformation, which consumes a large amount of plastic deformation energy.

Therefore, the Griffith formula must be modified to accurately reflect this phenomenon.

2. Mechanical properties of materials under uniaxial static tension

1. Soft coefficient of stress state

The ratio of the maximum shear stress, τmax, to the maximum normal stress, σmax, is called the stress state softness coefficient, denoted by α.

The larger α is, the larger the maximum shear stress component becomes, indicating a softer stress state and greater ease of plastic deformation in the material.

Conversely, the smaller α is, the harder the stress state becomes, leading to more brittle fracture.

2. How to understand the phenomenon of “notch strengthening” of plastic materials?

When a specimen has a notch, its yield stress is higher than that of a specimen under uniaxial tension due to the presence of triaxial stress, which is referred to as the “notch strengthening” phenomenon.

However, this “notch strengthening” cannot be considered a method of material strengthening, as it is solely a result of the plastic deformation of the material constrained by three-dimensional stress.

In this case, the material’s own value of σs remains unchanged.

3. The characteristics and application scope of uniaxial tension, compression, bending and torsion tests are comprehensively compared.

Revised:

In unidirectional tension, the normal stress component is large while the shear stress component is small, resulting in a hard stress state.

This test is typically applied to materials with low plastic deformation resistance and cutting resistance, known as plastic materials.

Unidirectional compression has a stress state softness coefficient of a=2, and is mainly used to test brittle materials.

Bending tests do not suffer from the specimen deflection that occurs during tension tests.

In bending, the stress distribution on the cross section reaches its maximum at the surface, making it an effective way to reflect surface defects in materials.

Torsion Test: The softness coefficient of stress state in torsion is higher than that in tension, making it an effective method for evaluating the strength and plasticity of materials that are brittle under tension.

In the torsion test, the stress distribution on the sample section is highest at the surface, making it highly sensitive to the material’s surface hardening and surface defects.

The torsion test results in approximately equal normal stress and shear stress.

The fracture surface in the torsion test is perpendicular to the sample axis and is often used to evaluate plastic materials.

In normal fracture, the angle between the fracture surface and the sample axis is approximately 45 degrees, which is due to normal stress. Brittle materials frequently exhibit this type of fracture surface.

4. Try to compare the similarities and differences between Brinell hardness test and Vickers hardness test principles, and compare the advantages and disadvantages of Brinell hardness test, Rockwell hardness test and Vickers hardness test and their application scope.

The principle of the Vickers hardness test is similar to the Brinell hardness test, as both methods calculate hardness values based on the load per unit area of the indentation.

The main difference between the two tests is the type of indenter used. In the Vickers hardness test, a diamond pyramid indenter with an angle of 136 degrees between opposite sides is employed. In contrast, the Brinell hardness test uses a hardened steel ball or a hard alloy ball as the indenter.

Advantages of Brinell hardness test:

The large indentation area of the Brinell hardness test makes it capable of reflecting the average performance of each constituent phase over a large area, and the test results are stable and highly repeatable.

As a result, the Brinell hardness test is particularly suitable for measuring the hardness of materials such as gray cast iron and bearing alloys.

Disadvantages of Brinell hardness test:

The large indentation diameter of the Brinell hardness test makes it generally unsuitable for direct inspection of finished products.

Furthermore, the need to replace the indenter diameter and load for materials with varying hardness, as well as the inconvenience of measuring the indentation diameter, are additional drawbacks of the test.

Advantages of Rockwell hardness test:

Easy and fast operation;

The indentation is small, and the workpiece can be inspected directly;

Disadvantages:

Poor representation due to small indentation;

The hardness values measured with different scales can neither be directly compared nor exchanged.

The Vickers hardness test has many advantages:

Accurate and reliable measurement;

You can select any load.

In addition, Vickers hardness does not have the problem that the hardness of different scales of Rockwell hardness cannot be unified, and the thickness of the test piece is thinner than that of Rockwell hardness.

Disadvantages of Vickers hardness test:

Its measuring method is troublesome, its working efficiency is low, the indentation area is small, and its representativeness is poor, so it is not suitable for routine inspection of mass production.

Related reading: Metal Hardness: The Definite Guide

3. Impact toughness and low temperature brittleness of materials

1. Low temperature brittleness, ductile brittle transition temperature.

When the temperature during testing drops below a certain temperature, tk (the ductile-brittle transition temperature), materials such as bcc or closely packed hexagonal crystal metals and alloys, particularly medium and low strength structural steels commonly used in engineering, undergo a transition from a ductile state to a brittle state, resulting in a significant decrease in impact absorption energy.

This transition is characterized by a change in fracture mode from micropore aggregation to transgranular cleavage and a change in fracture appearance from fibrous to crystalline, a phenomenon known as low-temperature brittleness.

2. The physical essence of low temperature brittleness and its influencing factors are explained.

At temperatures below the ductile-brittle transition temperature, the fracture strength is lower than the yield strength, resulting in brittle behavior at low temperatures.

A. Influence of crystal structure: Body centered cubic metals and their alloys have low temperature brittleness, while face centered cubic metals and their alloys generally have no low temperature brittleness.

The low temperature brittleness of BCC metals may be closely related to the late yielding phenomenon.

B. The influence of chemical composition: the content of interstitial solute elements increases, the higher energy decreases, and the ductile brittle transition temperature increases.

C. Influence of microstructure: refining grain and structure can increase the toughness of materials.

D. Influence of temperature: It is relatively complex, and brittle (blue brittle) occurs within a certain temperature range.

E. Effect of loading rate: Increasing the loading rate is like lowering the temperature, which increases the brittleness of the material and increases the ductile brittle transition temperature.

F. Influence of specimen shape and size: the smaller the curvature radius of notch, the higher tk.

3. The reason for improving toughness by refining grains?

Grain boundaries serve as resistance to crack propagation.

The reduction in the number of dislocations at the pre-grain boundary packing helps to reduce stress concentration.

An increase in the total grain boundary area reduces impurity concentration along the grain boundaries, thereby reducing the likelihood of intergranular brittle fracture.

4. Fracture toughness of materials

1. Low stress brittle fracture

When the working stress of large parts is not high, even far below the yield limit, brittle fracture often occurs, which is called low stress brittle fracture.

2. Explain the names and meanings of the following symbols: KIc; JIc; GIc; δc.

KIC (the stress-strain field intensity factor at the crack tip in the crack body) is a measure of plane strain fracture toughness and represents a material’s ability to resist unstable crack propagation under plane strain conditions.

JIc (the strain energy at the crack tip) is also known as fracture toughness and represents a material’s ability to resist crack initiation and propagation.

GIc represents the energy consumed per unit area to prevent unstable crack propagation in a material.

δC (crack opening displacement), also known as material fracture toughness, indicates a material’s ability to prevent crack expansion from starting.

3. Explain the similarities and differences between KI and KIc.

KI and KIC are two distinct concepts.

KI is a mechanical parameter that represents the strength of the stress-strain field at the crack tip in the crack body and is dependent on applied stress, sample size, and crack type, but is independent of the material.

On the other hand, KIC is a mechanical property index of the material that depends on internal factors such as composition and structure, but is not affected by external factors like applied stress and sample size.

The relationship between KI and KIC is similar to that between σ and σs, where KI and σ are mechanical parameters, and KIC and σs are mechanical property indexes of materials.

5. Fatigue property of materials

1. What are the characteristics of fatigue failure?

(1) This type of failure is a sudden and unexpected failure that occurs without noticeable plastic deformation before fatigue failure and is characterized by brittle fracture.

(2) Fatigue failure is a type of low stress cycle delayed fracture.

(3) Fatigue is highly sensitive to defects such as notches, cracks, and structural defects.

(4) Fatigue forms can be classified in several ways.

According to stress state, fatigue forms include bending fatigue, torsion fatigue, tension and compression fatigue, contact fatigue, and composite fatigue.

Based on stress level and fracture life, fatigue can be further classified into high cycle fatigue and low cycle fatigue.

2. How many characteristic areas of fatigue fracture surface?

Fatigue source, fatigue crack growth zone and transient fracture zone.

3. Try to describe the similarities and differences between σ-1and ΔKth.

σ-1 (fatigue strength) represents the infinite life fatigue strength of smooth specimens, which is suitable for traditional fatigue strength design and verification;

ΔKth (threshold value of fatigue crack growth) represents the infinite life fatigue performance of the crack sample, which is suitable for the design and fatigue strength check of the cracked parts.

6. Wear resistance of materials

1. How many types of wear are there? It shows their surface damage morphology.

Adhesion wear, abrasive wear, corrosion wear and pitting fatigue wear (contact fatigue).

Adhesion wear: The wear surface is characterized by scabs of different sizes on the surface of the parts.

Abrasive wear: groove formed by scratch or obvious furrow on friction surface.

Contact fatigue: there are many pits (pockmarks) on the contact surface, some of which are deep, and there are traces of fatigue crack growth lines at the bottom.

2. Is the statement “the harder the material, the higher the wear resistance” correct? Why?

Correct. Because the wear is inversely proportional to the hardness.

3. From the point of view of improving material fatigue strength, contact fatigue strength and wear resistance, the matters needing attention in chemical heat treatment are analyzed.

The residual compressive stress of the surface layer is increased while the surface strength and hardness are increased.

7. High temperature performance of materials

1. Explain the following terms:

Approximate specific temperature: T/Tm

Creep: This refers to the gradual plastic deformation of a material under the influence of constant temperature and load over an extended period of time.

Endurance Strength: This term refers to the maximum stress that a material can withstand without experiencing creep fracture, under a specific temperature and within a designated time frame.

Creep Limit: This represents a material’s resistance to high-temperature creep deformation.

Relaxation Stability: The term used to describe a material’s ability to resist stress relaxation is called relaxation stability.

2. The creep deformation and fracture mechanism of materials are summarized.

The main mechanisms of creep deformation in materials include dislocation slip, atomic diffusion, and grain boundary slip.

For polymer materials, molecular chain stretching under external force is also a contributing factor to creep.

Intercrystalline fracture is a common form of creep fracture, particularly at high temperatures and low stress levels. This is because the strength of polycrystalline grains and grain boundaries decreases with temperature, but the latter decreases faster, leading to lower grain boundary strength relative to grain strength at high temperatures.

There are two models to explain grain boundary fracture: the grain boundary sliding and stress concentration model, and the vacancy aggregation model.

3. The differences between creep deformation and plastic deformation mechanisms of metals at high temperatures are discussed.

The plastic deformation mechanism of metals is based on slip and twinning.

The creep deformation mechanism of metals is primarily driven by dislocation slip, diffusion creep, and grain boundary slip.

At high temperatures, the elevated temperature provides thermal activation for atoms and vacancies, allowing dislocations to move and continue to cause creep deformation.

Under the influence of external force, an uneven stress field is generated within the crystal, leading to differences in potential energy among atoms and vacancies. This results in directional diffusion from high potential energy to low potential energy.

8. Thermal properties of materials

1. Try to analyze the factors affecting the heat capacity of materials?

For solid materials, the heat capacity is not significantly impacted by the material’s structure.

In a first-order phase transition, the heat capacity curve changes abruptly and has an infinite value.

In a second-order phase transformation, the change occurs gradually over a specific temperature range and results in a finite maximum heat capacity.

2. Try to explain why the thermal conductivity of glass is often several orders of magnitude lower than that of crystalline solid.

Amorphous materials have low thermal conductivity because their short-range ordered structure can be considered as a crystal with extremely small grains.

Due to the small grain size and numerous grain boundaries, phonons are easily scattered, leading to significantly reduced thermal conductivity.

9. Magnetic properties of materials

1. Why is diamagnetism produced in materials?

Under the action of magnetic field, the orbital motion of electrons in matter produces diamagnetism.

2. What are the main applications of diamagnetic and paramagnetic susceptibility in metal research?

Determining the Maximum Solubility Curve in the Alloy Phase Diagram:

By utilizing the rule that single-phase solid solutions exhibit higher paramagnetism than two-phase mixed structures and the linear relationship between mixture paramagnetism and alloy composition, the maximum solubility of an alloy at a specific temperature and the alloy solubility curve can be determined.

Investigating the Decomposition of Aluminum Alloys:

The order-disorder transition, isomerism transition, and recrystallization temperature were studied to better understand the decomposition of aluminum alloys.

3. Explain the conditions under which ferromagnetism occurs.

For a metal to exhibit ferromagnetism, it is not only necessary for its atoms to have non-zero spin magnetic moments, but also for these moments to spontaneously align and generate spontaneous magnetization.

4. Try to explain the main performance marks of soft magnetic materials and hard magnetic materials.

Soft magnetic materials have a narrow hysteresis loop and are characterized by high magnetic conductivity and low Hc. In contrast, hard magnetic materials have a thick hysteresis loop, high Hc, Br, and (BH)m.

10. Electrical properties of materials

1. Explain the similarities and differences between the quantum free electron conduction theory and the classical conduction theory.

In a metal, the electric field created by positive ions is uniform and there is no interaction between the valence electrons and ions. This field is considered a property of the entire metal and allows for free movement of electrons throughout the metal.

According to the quantum free electron theory, the inner electrons of each atom in the metal retain the energy state of a single atom, while the valence electrons have different energy states due to quantization and have distinct energy levels.

The energy band theory also recognizes that the valence electrons in metals are shared and quantized in energy, but it suggests that the potential field created by ions in metals is not uniform, but instead changes periodically.

2. Why does the resistance of metal increase with temperature, while that of semiconductor decreases with temperature?

The rise in temperature intensifies ion vibration and increases the amplitude of thermal vibration, leading to increased atomic disorder, reduced electron movement, and increased scattering probability. These factors result in an increase in resistivity.

In semiconductors, conduction is mainly driven by electrons and holes. An increase in temperature increases the kinetic energy of electrons, leading to an increase in the number of free electrons and holes in the crystal, and thus an increase in conductivity and a decrease in resistance.

3. What are the three main indicators of superconductor performance?

(1) Critical transition temperature Tc

(2) Critical magnetic field Hc

(3) Critical current density Jc

4. The application of resistance measurement in metal research is briefly discussed.

The change of microstructure of metals and alloys is studied by measuring the change of resistivity.

(1) Measure the solubility curve of solid solution

(2) Measure the transformation temperature in shape memory alloy.

5. What are the conductive sensitive effects of semiconductors?

Thermal effect, photosensitive effect, pressure sensitive effect (voltage sensitive and pressure sensitive), magnetic sensitive effect (Hall effect and magnetoresistance effect), etc.

6. What are the main damage forms of insulating materials?

Electrical breakdown, thermal breakdown and chemical breakdown.

11. Optical properties of materials

1. The concept of linear optical performance and its basic parameters are briefly described.

Linear Optical Properties: When light of a single frequency is incident on a transparent medium that does not absorb light, its frequency does not change. When light of different frequencies is incident on the medium at the same time, there is no interaction between the light waves and no new frequency is produced.

When two beams of light intersect, if they are coherent light, interference will occur. If they are incoherent light, only the intensity of the light will combine, following the principle of linear superposition.

Other optical properties include refraction, dispersion, reflection, absorption, and scattering.

2. Try to analyze the feasibility of preparing transparent metal products?

It is not practical to use metals for visible light optics because they strongly absorb visible light. This is because the valence electrons in metals occupy an incomplete band and, after absorbing photons, are in an excited state. They can transfer energy through collisions and produce heat, but do not transition to the conduction band.

3. The conditions for producing nonlinear optical properties are briefly described.

The incident light is strong;

Symmetry requirements of crystals;

Phase matching.

Don't forget, sharing is caring! : )
Shane
Author

Shane

Founder of MachineMFG

As the founder of MachineMFG, I have dedicated over a decade of my career to the metalworking industry. My extensive experience has allowed me to become an expert in the fields of sheet metal fabrication, machining, mechanical engineering, and machine tools for metals. I am constantly thinking, reading, and writing about these subjects, constantly striving to stay at the forefront of my field. Let my knowledge and expertise be an asset to your business.

Up Next

Mastering CAD/CAM: Essential Technologies Explained

Basic Concepts of Computer-Aided Design and Computer-Aided Manufacturing Computer-aided design and computer-aided manufacturing (CAD/CAM) is a comprehensive and technically complex system engineering discipline that incorporates diverse fields such as computer [...]

Virtual Manufacturing Explained: Concepts & Principles

Concept of Virtual Manufacturing Virtual Manufacturing (VM) is the fundamental realization of the actual manufacturing process on a computer. It utilizes computer simulation and virtual reality technologies, supported by high-performance [...]

Understanding Flexible Manufacturing Systems: A Guide

A Flexible Manufacturing System (FMS) typically employs principles of systems engineering and group technology. It connects Computer Numerical Control (CNC) machine tools (processing centers), coordinate measuring machines, material transport systems, [...]

Exploring 4 Cutting-Edge Nanofabrication Techniques

Just as manufacturing technology plays a crucial role in various fields today, nanofabrication technology holds a key position in the realms of nanotechnology. Nanofabrication technology encompasses numerous methods including mechanical [...]

Ultra-Precision Machining: Types and Techniques

Ultra-precision machining refers to precision manufacturing processes that achieve extremely high levels of accuracy and surface quality. Its definition is relative, changing with technological advancements. Currently, this technique can achieve [...]

Exploring High-Speed Cutting: Tech Overview & Application

Cutting machining remains the most prominent method of mechanical processing, holding a significant role in mechanical manufacturing. With the advancement of manufacturing technology, cutting machining technology underwent substantial progress towards [...]

Top 7 New Engineering Materials: What You Need to Know

Advanced materials refer to those recently researched or under development that possess exceptional performance and special functionalities. These materials are of paramount significance to the advancement of science and technology, [...]

Metal Expansion Methods: A Comprehensive Guide

Bulge forming is suitable for various types of blanks, such as deep-drawn cups, cut tubes, and rolled conical weldments. Classification by bulge forming medium Bulge forming methods can be categorized [...]
MachineMFG
Take your business to the next level
Subscribe to our newsletter
The latest news, articles, and resources, sent to your inbox weekly.
© 2024. All rights reserved.

Contact Us

You will get our reply within 24 hours.
